Duplex Service Drop All Aluminium Conductor With Various Grade Voltage Silver

I'm Online Chat Now

Duplex Service Drop All Aluminium Conductor With Various Grade Voltage Silver

China Duplex Service Drop All Aluminium Conductor With Various Grade Voltage Silver supplier
Duplex Service Drop All Aluminium Conductor With Various Grade Voltage Silver supplier Duplex Service Drop All Aluminium Conductor With Various Grade Voltage Silver supplier Duplex Service Drop All Aluminium Conductor With Various Grade Voltage Silver supplier Duplex Service Drop All Aluminium Conductor With Various Grade Voltage Silver supplier

Large Image :  Duplex Service Drop All Aluminium Conductor With Various Grade Voltage Silver

Product Details:

Place of Origin: China
Brand Name: Sanwu
Certification: ISO, CCC, TUV, CE
Model Number: AAAC-002

Payment & Shipping Terms:

Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: New wooden drum, Reel, Circle or according to customer's request
Delivery Time: According to customer's request, usually 2-4 weeks.
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 700 Kilometer/Kilometers per Month conductor
Contact Now
Detailed Product Description
Material: Aluminum Application: Overhead Transmission Line
Voltage: Up To 1000KV Certification: ASTM B, BS, DIN, IEC
Type: Low & Medium Voltage Life Span: More Than 30 Years

Bull 1/0-19 size & No.of wires duplex service drop aluminum conductor

Description:

The bare conductor:AAC,AAAC,ACSR,AACSR,ACAR and Galvanized steel wire, are used in overhead electric power transmission and distribution lines with various grade voltage.



Products Bull 1/0-19 size & No.of wires duplex service drop aluminum conductor
Type Bull aluminum conductor
Material Aluminum
Power Capacity 1-10KV
Application Overhead
Galvanization No
Packing New wooden drum, Reel, Circle or according to customer's request
payment term L/C, T/T, Western Union, MoneyGram



Life Period

More than 25 years, it is according to installing environment



Certificates

ISO,CCC, TUV, CE







Construction



All Aluminum-Alloy Conductors (AAAC) is a concentric-lay-stranded conductor consisting of aluminum-alloy wires available in both single layer and multi-layer constructions.

Standard 6201-T81 high strength aluminum conductors, conforming to ASTM Specification B-399, are concentric-lay- stranded, similar in construction and appearance to 1350 grade aluminum conductors. Standard 6201 alloy conductors are similar to other alloy conductors commercially known as Ardival, Aldrey or Almelec. They were developed to fill the need for an economical conductor for overhead applications requiring higher strength than that obtainable with 1350 grade aluminum conductors, but without a steel core. The DC resistance at 20°C of the 6201-T81 conductors and of the standard ACSRs of the same diameter are approximately the same. Conductors of the 6201-T81 alloys are harder and, therefore, have a greater resistance to abrasion than conductors of 1350-H19 grade aluminum.

Duplex Service Drop All Aluminium Conductor With Various Grade Voltage Silver

Features

  • High strength to weight ratio
  • Better sag characteristics
  • Improved electrical properties
  • Excellent resistance to corrosion

Application



Aluminium Conductors are predominantly used in Overhead Line applications and for primary and secondary power distribution.

All Aluminum-Alloy Conductors (AAAC) can be used in Medium, High and Extra-High voltage transmission lines. AAAC offers better sag performance due to the high strength-to-weight ratio provided by the aluminum-alloy. In addition, AAAC provides a higher corrosion resistance than ACSR conductors.

Duplex Service Drop All Aluminium Conductor With Various Grade Voltage Silver



Specification



(1) all aluminium conductor (AAC)
(2) all aluminimum alloy conductor(AAAC)
(3) aluminum conductor steel reinforced (ACSR)
(4) anti-corrosion type ACSR
(5) aluminimum conductor aluminimum clad steel reinforced(ACSR/AW)
(6)rear earth aluminimum conductor steel reinforced(ACSR/RE)
(7)aluminimum conductor aluminimum alloy reinforced(ACAR)

Duplex Service Drop All Aluminium Conductor With Various Grade Voltage Silver
