Overhead Bare All Aluminium Alloy Conductor ASTM / IEC Standard 150mm2

China Overhead Bare All Aluminium Alloy Conductor ASTM / IEC Standard 150mm2 supplier

Large Image :  Overhead Bare All Aluminium Alloy Conductor ASTM / IEC Standard 150mm2

Product Details:

Place of Origin: China
Brand Name: Sanwu
Certification: IS09001, IS014001,OHSAS18001. CCC
Model Number: AAAC

Payment & Shipping Terms:

Minimum Order Quantity: 3000 meters
Price: Negotiate
Packaging Details: Non returnable wooden / steel reels
Supply Ability: 50000 Kilogram per day
Contact Now
Detailed Product Description
Materials: 1350 Alloy Application: Cable Construction
Certification: TUV Rates: 0.6/1kv
Standard: ASTM, BS, IEC, DIN Type: LV

Overhead bare ASTM /IEC standard AAAC 150mm2 All Aluminum Alloy stranded Conductor

All Aluminum Alloy Conductor(AAAC 150mm2)

All Aluminum Alloy Conductor(AAAC 150mm2),characterized by light weight and high strength,are used in overhead electric power transmission and distribution lines with various grade voltages.Aluminum Alloy Wires are concentrically stranded. AAAC is recommended for use as bare overhead conductor for primary and secondary distribution and in cases where high strength-to-weight ratio is required .



AAAC 150mm2 has a good corrosion resistance due to being composed out of aluminum alloy wires only, minimum conductivity of 52% IACS, high breaking strength per weight and normal creep values. AAAC has the highest strength per weight among all bare overhead conductors



Tures and Benefits Of AAAC 150mm:

Aluminum alloy conductors have a number of advantages over the use of the ACSR or all aluminum

conductors. Lower power losses than for equivalent single aluminum-

layer ACSR conductors. (The inductive effect of the steel core in the ACSR is eliminated).

• Simpler fittings than those required for ACSR.

• Excellent corrosion resistance in environments conducive to galvanic corrosion in ACSR.

• Strength and sag approximately the same as for equivalent 6/1 and 26/7 ACSR conductors.

• Outside diameters are the same as for standard ACSR conductors, permitting interchangeability of fittings.

• Greater resistance to abrasion than that for 1350 wires in all-aluminum or ACSR conductors.



Service Performance

(1).The permissible long-time operating temperature for aerial conductor is 70oC.

(2).Under the circumstance that rare climate is occuring and ice coverage rate low in heavy ice area,the biggest stress of cable at the lowest point of the sag should not exceed 60% of the short-time destructive power.

(3).When connecting conductors,the conductor beside the connecting tube cant be prominent.Otherwise,the force on the operating conductors will be unbalanced.After connectors are install,the connecting tube should be painted by moisture-proof varnish in order to protect it from corrosion.

(4).Under installaion,the arc downing stress of all the conduct ors should be the same.With in the permissible distance of crossing buildings or dropping to the ground,the stress can be 10-15% higher than regular stress.





Applications oF AAAC150mm2:

AAAC 150mm2 aluminum alloy conductors are extensively used for overhead distribution and transmission lines adjacent to ocean coastlines where there can be a problem of corrosion in the steel of an ACSR construction.The inductive effect of the ACSR's steel core is eliminated, hence increasing the operating efficiency of the line.



Material Standard Of AAAC 150mm

(1).The hard aluminum conductor used for AAC and ACSR conforms to the standard GB/T 17048-1997(equivalent to IEC 60889:1987).

(2).The zinc coated steel wire used for ACSR conforms to IEC 60888:1987.

(3).Production can be arranged according to customers requirements for material standard,etc.

Construction of All Aluminum Conductor and Aluminum Conductor Steel Reinforced



ELECTRICAL PROPERTIES of 2/0 AWG All aluminium alloy conductor

Density@20ºC 2.70 kg/dm
Temperature Coefficient@20°C 0.00360 (°C)
Resistivity@20°C 0.0326 Ohms mm2 /m
Linear Expansivity 23 x10-6 (°C)



SERVICE CONDITIONS of 2/0 AWG All aluminium alloy conductor

Ambient Temperature -5°C - 50°C
Wind Pressure 80 – 130kg/m2
Seismic Acceleration 0.12 - 0.05g
Isokeraunic Level 10 – 18
Relative Humidity 5 – 100%



CONSTRUCTION PARAMETERS of 2/0 AWG All aluminium alloy conductor

Nominal Area Stranding Overall Weight Rated Electrical Current
Diameter Strength Resistance Rating*
AWG&MCM mm2 No.×mm mm kg/km KN Ω/Km A
6 13.2 7/1.55 4.65 36.2 4.18 2.5361 69
4 21.1 7/1.96 5.88 57.9 6.69 1.586 93
2 33.5 7/2.47 7.41 92 10.6 0.9987 123
0 53.5 7/3.12 9.36 146.8 17 0.62592 165
2/0 67.3 7/3.50 10.5 184.8 20.4 0.49738 190
3/0 84.9 7/3.93 11.79 233 25.7 0.3945 219
4/0 107 7/4.42 13.26 294.7 32.5 0.31188 253
250 126 19/2.91 14.55 346.7 38.8 0.26509 280
300 152 19/3.19 15.95 416.7 46.6 0.22059 313
350 178 19/3.45 17.25 487.3 52 0.1886 345
400 203 19/3.69 18.45 557.5 59.5 0.16486 375
450 228 19/3.91 19.55 626 66.8 0.14683 402
500 253 19/4.12 20.6 695 74.2 0.13224 429
550 279 37/3.10 21.7 766.2 83.9 0.11995 455
600 303 37/3.23 22.61 831.9 91 0.11049 478
650 330 37/3.37 23.59 905.5 94.9 0.1015 504
700 354 37/3.49 24.43 971.2 101 0.09464 525
750 381 37/3.62 25.34 1045 109 0.08796 549
800 404 37/3.73 26.11 1109 116 0.08285 569
900 456 37/3.96 27.72 1250 131 0.07351 612
1000 508 37/4.18 29.26 1393 146 0.06597 653
1250 631 61/3.63 32.67 1732 179 0.05306 743
1500 759 61/3.98 35.82 2082 215 0.04414 827
1750 886 61/4.30 38.7 2431 251 0.03781 904

(*) Note: The values of current rating mentioned in above Table are based on wind velocity of 0.6 metre/second, solar heat radiation of 1200 watt/metre2, ambient temperature of 50° C & conductor temperature of 80°C.

Overhead Bare All Aluminium Alloy Conductor ASTM / IEC Standard 150mm2



Overhead Bare All Aluminium Alloy Conductor ASTM / IEC Standard 150mm2

Luoyang Sanwu Cable Co., Ltd., with registered capital of 100 million RMB, is a high-tech development company for scientific research, industry producing and trading , offering a diverse selection of quality wires and cables to industrial customers in 33 countries worldwide. The leading products are ACSR, overhead conductor, AAAC, AAC, power cable, BLXY, home-used wire and so on.
Sanwu cable owns variously advanced equipment and large quantities of high skilled professionals. With complete management system, advanced production process, strict testing procedure and reliable product quality, we have successively got IS09001, IS014001,OHSAS18001,TUV Certificate, CCC(China Compulsory Certification), the national industrial production license and so on.
In terms of quality, It is highly controlled by our company to ensure that all the products we sell meet your requirements and give you reassurance with excellent after-sale service.In terms of service, we are focusing on your need, we concern what you concern and request what you request to provide a more satisfied service.

Overhead Bare All Aluminium Alloy Conductor ASTM / IEC Standard 150mm2
