0.6-1kv Direct Burial Aluminium Conductor Alloy Reinforced High Mechanical Strength

I'm Online Chat Now

0.6-1kv Direct Burial Aluminium Conductor Alloy Reinforced High Mechanical Strength

0.6-1kv Direct Burial Aluminium Conductor Alloy Reinforced High Mechanical Strength
0.6-1kv Direct Burial Aluminium Conductor Alloy Reinforced High Mechanical Strength 0.6-1kv Direct Burial Aluminium Conductor Alloy Reinforced High Mechanical Strength

Large Image :  0.6-1kv Direct Burial Aluminium Conductor Alloy Reinforced High Mechanical Strength

Product Details:

Place of Origin: Luoyang,Henan Province,China
Brand Name: Sanwu
Certification: IS09001; IS014001;OHSAS18001;CCC
Model Number: ACAR

Payment & Shipping Terms:

Minimum Order Quantity: 1000M
Price: USD 0.2-20 per meter
Packaging Details: wooden drums
Delivery Time: 5-15 work days
Payment Terms: L/C, T/T
Supply Ability: 50km / week
Detailed Product Description
Conductor: Aluminum Core: Aluminum Alloy
Color: Silver Insulation: Bare
Rated Voltage: 0.6-1kv;1-35KV Application: Aerial Power Distribution Lines
Service Life: 70 Years Warranty: 1 Year
High Light:

aluminum conductor alloy reinforced

,

transmission line conductor

Product Name Aluminum Conductor Alloy Reinforced (ACAR)
Conductor Aluminum/Copper
Construction Aluminum Stranded & Aluminum Alloy Reinforce
Colors Assorted upon request
Voltage 600-1000V, 1KV-35KV
Application Used as bare overhead conductor for power distribution lines
Standards GB/T 1179, IEC 60889, IEC 61089,BS,DIN and ICEA upon request

ACAR has aluminium 1350 H-19 wires concentrically stranded around a 6201-T81 aluminium alloy core. Typically, the 6201-T81 is the conductor core, but in certain designs, the 1350 H-19 and the 6201-T81 wires may be stranded in the same layer.

ACAR is an excellent conductor choice where current carrying capacity ,higher strenghth and lower conductor weight are critical to the line design.

1.Applications:

ACAR is used as bare cable for overhead transmission and distribution lines and also as bus-bar in substations where is highly suitable considering the mechanical and electrical characteristics.

As comparison with ACSR of same weight, ACAR can offers higher mechanical strength.

2.Features :

Aluminum Conductor Alloy Reinforced (ACAR)

cable is an excellent conductor choice where current

carrying capacity, higher strength and a lower conductor

weight are critical to the line design.

3.Construction:

Wires of Aluminium 1350-H19 is concentrically stranded on Aluminium Alloy 6201 core. The number of wires of each one depends on the cable design.

In some cable constructions the wires of Aluminium Alloy 6201 can be distributed in layers throughout the Aluminium 1350-H19.

4.Part of ACAR(6201) conductors of ASTM sizes.

Size Kcmil Stranding No.& Dia.(In.) Cross Sectional Area(Square In.) Nominal Conductor Dia. (In.)

Nominal weight

(Lbs/1000FT)

Rated Strength

( Lbs)

1350 6201 1350 6201 Total
503.6 15*0.1628 4*0.1628 0.3122 0.0833 0.3955 0.814 473 10500
587.2 15*0.1758 4*0.1758 0.3644 0.0971 0.4612 0.879 551 12200
649.5 18*0.1325 19*0.1325 0.2482 0.2620 0.5102 0.927 608 16600
653.1 12*0.1854 7*0.1854 0.3240 0.1890 0.5130 0.927 612 15400
739.8 18*0.1414 19*0.1414 0.2827 0.2983 0.5810 0.990 693 18800
853.7 30*0.1519 7*0.1519 0.5437 0.1268 0.6705 1.063 801 17500
853.7 24*0.1519 13*0.1519 0.4349 0.2356 0.6705 1.063 800 19300
927.2 24*0.1583 13*0.1583 0.4723 0.2559 0.7282 1.108 869 20900

5.Packaging and Delivery:

0.6-1kv Direct Burial Aluminium Conductor Alloy Reinforced High Mechanical Strength 0

Packaging Details

Wooden package optional:
Size: 0.5*0.5*0.5m
0.6*0.6*0.6m; 0.7*0.7*0.7m
1.1*1.1*0.8m; 2.2*2.2*1.8m
Or suitable meters according to your needs.

Delivery Time

Generally it is 5-10 days if the goods are in stock,or it is 15.
