| Place of Origin: | Henan |
| Brand Name: | Sanwu |
| Certification: | ISO CCC |
| Model Number: | ACSR-010 |
| Minimum Order Quantity: | 1000M |
|---|---|
| Price: | Negotiable |
| Packaging Details: | New Wooden drum, reel, circle, or according to customers request. |
| Delivery Time: | 1-15days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 tons per day |
| Keywords: | Aluminum Conductor Steel Reinforced | Original Place: | Henan, China |
|---|---|---|---|
| Life Span: | More Than 30 Years | Voltage: | Medium And Low Voltage |
| Standard: | ASTM B232 | Conductor: | Aluminum |
| High Light: | medium voltage aluminum conductor steel reinforced,astm b232 aluminum conductor steel reinforced,low voltage aluminium conductor steel reinforced |
||
Medium And Low Voltage Aluminum Conductor Steel Reinforced ASTM B232
The aluminum alloy and temper used for the outer strands in the United States and Canada is normally 1350-H19 and elsewhere is 1370-H19, each with 99.5+% aluminum content. The temper of the aluminum is defined by the aluminum version's suffix, which in the case of H19 is extra hard. To extend the service life of the steel strands used for the conductor core they are normally galvanized, or coated with another material to prevent corrosion. The diameters of the strands used for both the aluminum and steel strands vary for different ACSR conductors.
Acsr Dog Conductor Feature:
a. High tensile strength
b. Long life
c. Light in weight
Acsr Dog Conductor specification
| Code | Size (AWG/MCM) | Number of Strands(mm) | Weight(kg/km) | Rated Strength(kg) |
| Rose | 4 | 7*1.96 | 58.3 | 399 |
| Iris | 2 | 7*2.47 | 92.7 | 611 |
| Pansy | 1 | 7*2.78 | 117 | 740 |
| Poppy | 1/0 | 7*3.12 | 147.5 | 897 |
| Aster | 2/0 | 7*3.5 | 186 | 1375 |
Service Performance:
(1). The permissible long-time operating temperature for aerial conductors is 70℃.
(2). Under the circumstance that a rare climate is occurring and the ice coverage rate is low in heavy ice areas, the biggest stress of cable at the lowest point of the sag should not exceed 60% of the short-time destructive power.
(3). When connecting conductors, the conductor beside the connecting tube cant be prominent. Otherwise, the force on the operating conductors will be unbalanced. After connectors are install, the connecting tube should be painted by moisture-proof varnish in order to protect it from corrosion.
(4). Under installation, the arc downing stress of all the conductors should be the same. With in the permissible distance of crossing buildings or dropping to the ground, the stress can be 10-15% higher than regular stress.
