Concentric Lay Stranded ACAR Conductor ASTM Specifications B230 B398 And B524

Concentric-Lay-Stranded ACAR Conductor ASTM Specifications B230, B398 And B524.

Made of round aluminum 1350-H19 (extra hard) and round aluminum 6201-T81 wires, ACAR is a concentric-laystranded conductor. There are single and multi-layer constructions for ACAR conductors. These options offer the current carrying capacity and requisite strength for the specified applications. ACAR conductors are stronger and have a greater ampacity than ACSR conductors for the same weight.

1.Standard

ASTM B524 ,B 230, B 398, IEC61089, etc Application

2.Construction

ACAR has aluminium 1350 H-19 wires concentrically stranded around a 6201-T81 aluminium alloy core. Typically, the 6201-T81 is the conductor core, but in certain designs, the 1350 H-19 and the 6201-T81 wires may be stranded in the same layer

3.Features

1. ACAR offers excellent balance mechanical and electrical properties.

2.It has excellent corrosion resistance , owing to the compatible materials in the centre and the outer layers.

3.It is a compromise choice between AAC,ACSR,and AAAC.

4.It has 1350 designates grade of pure aluminium.

5. It has 6201 designates aluminium alloy grade.

4.Part of ACAR(6201) conductors of ASTM sizes.

5.Packaging and Delivery:

Packaging Details

Wooden package optional:
Size: 0.5*0.5*0.5m
0.6*0.6*0.6m; 0.7*0.7*0.7m
1.1*1.1*0.8m; 2.2*2.2*1.8m
Or suitable meters according to your needs.

Delivery Time

Generally it is 5-10 days if the goods are in stock,or it is 15.
