0.6/1kV LV Overhead Aerial Cable Class 2 Stranded Aluminium

0.6/1kV LV Overhead Aerial Cable Class 2 Stranded Aluminium

0.6/1kV LV Overhead Aerial Cable Class 2 Stranded Aluminium
0.6/1kV LV Overhead Aerial Cable Class 2 Stranded Aluminium
0.6/1kV LV Overhead Aerial Cable Class 2 Stranded Aluminium
Product Details:
Place of Origin: Henan
Brand Name: Sanwu
Certification: ISO CCC
Model Number: Overhead Aerial Cable
Payment & Shipping Terms:
Minimum Order Quantity: 1000M
Price: Negotiable
Packaging Details: Wooden drum, steel drum, steel-wooden drum
Delivery Time: 1-15days
Payment Terms: T/T, L/C, Western Union, MoneyGram, D/A, D/P
Supply Ability: 200 tons per day
Contact Now
Detailed Product Description
Application: Overhead And Distribution Name: Overhead Aerial Cable
Production Ability: 50KM Per Day Delivery Port: Qingdao
Payment Terms: T/T,L/C Validity: Class 2 Stranded Aluminium
Highlight:

Class 2 LV Overhead Aerial Cable

,

0.6/1kV LV Overhead Aerial Cable

,

Stranded Aluminium LV Overhead Aerial Cable

0.6/1kV LV Overhead Aerial Cable Class 2 Stranded Aluminium



1.Applications

For distribution, low power overhead networks are in metropolitan, urban and rural areas. For supply of remotefacilities and villages of temporary and permanent character. For above-ground house connections.

2.Specification

service drop cable meets or exceeds the following ASTM specifications:

B-230 Aluminum Wire, 1350-H19 for Electrical Purposes.

B-231Aluminum Conductors, Concentric-Lay-Stranded.

B-232Aluminum Conductors, Concentric-Lay-Stranded, Coated Steel Reinforced (ACSR).

B-399Concentric-Lay-Stranded 6201-T81 Aluminum Alloy Conductors.

B-901Compressed Round Stranded Aluminum Conductors Using Single Input Wire

3.Construction

Conductors are concentrically stranded, compressed 1350 H-19 aluminum. Insulated with either polyethylene or

crosslinkedpolyethylene (XLP). Neutral messengers are concentrically stranded 6201, AAC, or ACSR.

4.Teachnical Data

A.Duplex service drop cable:

Code word: ABC cable Chihuahua, ABC cable Vizsla, ABC cable Harrier, ABC cable Whippet, ABC cable Schnauzer, ABC cable Heeler, ABC cable Pekingese, ABC cable Collie, ABC cable Dachshund, ABC cable Spaniel, ABC Cable Doberman, ABC cable Malemute, ABC cable Setter, ABC cable Shepherd, ABC cable Eskimo, ABC cable Terrier, AB cable Chow, ABC cable Bull

B.Triplex service drop cable



Code Name Phase Conductor Bare Neutral Messenger Weight Per 1000ft (lbs) Ampacity(amps)
Size AWG Stranding Insulation Thickness(mls) Size AWG Stranding Breaking Strength(lbs) XLPE Poly XLPE Poly
6201 ALLOY NEUTRAL-MESSENGER
Minex 6 Solid 45 6 7 1,110 106.6 102.9 85 70
Hippa 6 7 45 6 7 1,110 113.2 105.7 85 70
Prawn 4 Solid 45 4 7 1,760 158.4 154.1 115 90
Barnacles 4 7 45 4 7 1,760 168.3 158.2 115 90
Shrimp 2 7 45 2 7 2,800 253.7 239.7 150 120
Gammarus 1/0 7 60 1/0 7 4,460 411.7 386.0 205 160
Leda 1/0 19 60 1/0 7 4,460 402.7 386.0 205 160
Dungenese 2/0 7 60 2/0 7 5,390 506.8 476.3 235 185
Cyclops 2/0 19 60 2/0 7 5,390 495.3 476.3 235 185
Dlustra 3/0 19 60 3/0 7 6,790 611.4 589.1 275 215
Lepas 4/0 19 60 4/0 7 8,560 757.1 730.5 315 245
6201 ALLOY REDUCED NEUTRAL-MESSENGER
Artemia 4 Solid 45 6 7 1,110 141.4 137.1 115 90
Crab 4 7 45 6 7 1,110 151.3 141.2 115 90
Solaster 2 7 45 4 7 1,760 226.6 212.6 150 120
Sandcrab 1/0 7 60 2 7 2,800 368.8 343.1 205 160
Echinus 1/0 19 60 2 7 2,800 358.8 343.1 205 160
Crayfish 2/0 7 60 1 7 3,530 452.6 422.5 235 185
Sipho 2/0 19 60 1 7 3,530 441.0 422.5 235 185
Fulgar 3/0 19 60 1/0 7 4,460 543.4 521.1 275 215
Arca 4/0 19 60 2/0 7 5,390 671.2 644.6

We could produce most of the standards cables, such as ASTM, BS, CSA, DIN, GB and IEC Standards, etc.
ISO9001:2008, OHSAS, CCC, TUV Certifications.
