ACSR Cable AWG\ASTM\BS Standard Aluminium Conductor Aluminium Clad Steel Reinforced Conductor

This ACSR (Aluminium Conductor Steel Reinforced) cable is manufactured with a stranded aluminium conductor and an aluminium‑clad steel reinforced core, designed for overhead power transmission and distribution systems. The cable is produced in accordance with ASTM B549, ASTM B232, and BS 215‑2 specifications, with conductor sizes available in AWG (American Wire Gauge) designations. The aluminium‑clad steel core provides mechanical reinforcement while eliminating the risk of galvanic corrosion between the core and the outer aluminium strands—a limitation inherent in conventional galvanized steel core ACSR designs. The conductor consists of concentric‑lay stranded aluminium 1350‑H19 wires surrounding the aluminium‑clad steel core, offering a combination of electrical conductivity and tensile strength. This cable is suitable for long‑span overhead installations where both mechanical load‑carrying capacity and stable electrical performance are required.

Standard
ASTM, IEC, GB, NFC 33-209

A: Duplex Service Drop

B.Triplex Service Drop

C. Quadruplex Service Drop
    Used to supply 3 phase power, usually from a pole- mounted transformer, to the user's service head where connection to the service entrance cable is made. To be used at voltages of 600 volts or less phase to phase and at conductor temperatures not to exceed 75°C for polyethylene insulated conductors or 90°C for crosslinked polyethylene (XLP) insulated conductors.
Construction
    Conductors are concentrically stranded, compressed 1350-H19 aluminum. Insulated with either polyethylene or XLP crosslinked polyethylene. Neutral messengers are concentrically stranded AAC/AAAC/ACSR. One conductor is manufactured with an extruded ridge for phase identification.

Features:

• Aluminium‑Clad Steel Core Design – The steel core wires are coated with a continuous aluminium layer, preventing bimetallic corrosion and ensuring compatibility with the outer aluminium conductor strands over the cable's service life.
• Concentric‑Lay Stranding – Outer aluminium wires and the core are stranded in concentric layers, providing uniform current distribution and stable mechanical behaviour under tension.
• Multiple Standard Compliance – Manufactured to ASTM B549 (aluminium‑clad steel reinforced), ASTM B232 (standard ACSR), and BS 215‑2, ensuring compatibility with international overhead line design practices.
• Overhead Service Optimisation – The cable construction is tailored for overhead applications, balancing electrical conductivity with the mechanical strength required for extended span lengths and varied climatic conditions.

Applications:

Producing Process:

Packing & Delivery:
Wooden drums with dimater 1.1m, 1.2m, 1.6m, 1.8m and 2.2m etc.;

Aluminium conductors are commonly wound onto wooden or steel reels, which provide protection during transport and handling.
20GP, 40GP and 40HQ containers

Customers Visit:

    All wires and cables are produced in strict accordance with EC, SAA CCC, ISO, ASTM, DIN, VED, JIS and other standard. As one manufacturer, here we can also provide customized services for various special types of cables according to customer needs.
    We always adheres to the enterprise spirit of "quality wins customers, reputation creates benefits", and sincerely welcomes friends from all over the world to visit our company and cooperate.

FAQ:

Q1. Are you factory, can I get factory low price?

Yes, we are a cable factory in Henan province, China. We will provide the best quality at a reasonable ex-work price.

Q2. How can I get a sample to check your quality?

After price confirmation, you can require samples to check our quality. The sample is free, but the freight charge should be paid.

Q3. Can I put my logo/company brand on the cable?

Yes, OEM ODM is available. Your logo can be marked on the cable as required.

Q4. What about the lead time for mass production?

Honestly, it depends on the order quantity and the season you place the order.

Q5. Certificate of your cable wire?

ISO9001, ISO14001, CE, and RoHS. Its products comply with international common standards such as IEC, BS, VDE, and GB
