Name: 0.6/1kV JKLYJ ABC Cable Aluminum Conductor XLPE Insulated Overhead Electrical Cable for Power Grid
Brand: Luoyang Sanwu Cable Co., Ltd.,
SKU: xlpe insulated cables
Price: 9.20 USD
Availability: InStock

Home Products XLPE Insulated Cable

0.6/1kV JKLYJ ABC Cable Aluminum Conductor XLPE Insulated Overhead Electrical Cable for Power Grid

Product Details:

Place of Origin:	Henan
Brand Name:	Sanwu
Certification:	ISO CCC
Model Number:	xlpe insulated cables

Payment & Shipping Terms:

Minimum Order Quantity:	1000M
Price:	USD 0.2-20 per meter
Packaging Details:	wooden drums
Delivery Time:	1-15days
Payment Terms:	L/C, T/T
Supply Ability:	200 tons per day

Contact Now

Detailed Product Description

Name:	XLPE Shielded Cable	Insulation:	XLPE
Rated Voltage:	0.6-1kv	Standard:	IEC 60502-1
Sheath:	PVC	Package:	Wooden Drum
Conductor Type:	Stranded	Application:	Power Distribution, Construction, Underground, Etc.
Highlight:	0.6/1kV JKLYJ ABC cable , aluminum conductor XLPE insulated cable , overhead electrical cable for power grid

Product Overview

This 0.6/1kV JKLYJ ABC (Aerial Bundled Cable) features aluminum conductors insulated with cross-linked polyethylene (XLPE), specifically designed for low-voltage overhead power distribution within utility grids. The cable comprises multiple insulated phase conductors twisted together with a neutral messenger, forming a compact, self-supporting bundle that eliminates the need for separate cross-arms and spacers.

Technical Specifications

Manufactured to IEC 60502-1 standards, this cable provides enhanced thermal resistance and dielectric strength, ensuring stable performance under sustained electrical loading and ambient temperature variations.

Specification Table

SPEC mm²	Conductor Structure	Insulation Material	Insulation Thickness (mm)	Approx Overall Diameter (mm)	Approx Weight (kg/km)
116+116	7/1.72	XLPE or PVC/PE	1.2	12.5	110.1
125+125	7/2.15	XLPE or PVC/PE	1.2	14.9	163.9
135+135	7/2.54	XLPE or PVC/PE	1.4	17.5	229.0
150+150	7/2.92	XLPE or PVC/PE	1.4	20.1	300.0
170+170	19/2.15	XLPE or PVC/PE	1.4	23.6	423.2
195+195	19/2.54	XLPE or PVC/PE	1.6	27.6	585.4
216+116	7/1.72	XLPE or PVC/PE	1.2	14.2	175.8
225+125	7/2.15	XLPE or PVC/PE	1.2	16.7	258.4
235+135	7/2.54	XLPE or PVC/PE	1.4	19.7	361.2
250+150	7/2.92	XLPE or PVC/PE	1.4	22.5	472.1
270+170	19/2.15	XLPE or PVC/PE	1.4	26.1	658.3
295+195	19/2.54	XLPE or PVC/PE	1.6	30.5	908.2
316+116	7/1.72	XLPE or PVC/PE	1.2	16.3	241.5
325+125	7/2.15	XLPE or PVC/PE	1.2	19.1	353.6
335+135	7/2.54	XLPE or PVC/PE	1.4	22.5	493.5
350+150	7/2.92	XLPE or PVC/PE	1.4	25.7	644.1
370+170	19/2.15	XLPE or PVC/PE	1.4	29.7	895.2
395+195	19/2.54	XLPE or PVC/PE	1.6	34.6	1233.5

Manufacturing Process

Applications

Low-Voltage Distribution Networks - Serving as the final overhead leg from pole-mounted transformers to consumer service points in residential and commercial areas
Rural Electrification Feeders - Deployed along countryside roads and agricultural land, where the insulated bundle minimizes outage risks from branches and animal contact
Urban Grid Retrofits - Replacing aged bare conductors in city streets to improve reliability and reduce fault incidence caused by environmental factors
Industrial Park Service Loops - Overhead supply to small factories and workshops, providing three-phase or single-phase power with simplified pole mounting
Temporary Grid Extensions - Used for rapid deployment of overhead lines during emergency restoration or short-term construction projects

Packaging & Delivery

Packaging Details

Wooden package optional in various sizes: 0.5×0.5×0.5m, 0.6×0.6×0.6m, 0.7×0.7×0.7m, 1.1×1.1×0.8m, 2.2×2.2×1.8m, or customized dimensions according to your requirements.

Delivery Time

Typically 5-10 days for in-stock items, or 15-20 days for custom orders depending on quantity.

Why Choose Our JKLYJ ABC Cables

Standard Compliance - Produced in accordance with applicable overhead cable standards with routine testing to verify insulation integrity and conductor resistance
Material Traceability - Aluminum rod and XLPE compound sourced from qualified suppliers with material certificates retained for each production batch
Installation Support - Technical data sheets covering cable dimensions, weight, and recommended clamping methods to assist with project planning
Customized Lengths and Configurations - Accommodating orders for specific conductor cross-sections and neutral configurations to meet your grid design requirements

Frequently Asked Questions

Are you a trading company or manufacturer?

We are a manufacturer.

How long is your delivery time?

Generally 5-10 days if the goods are in stock, or 15-20 days if not in stock, depending on quantity.

Do you provide samples? Is it free or extra?

Yes, we offer samples free of charge but do not cover the freight costs.

What are your payment terms?

Payment ≤ 1000USD: 100% in advance. Payment ≥ 1000USD: 30% T/T in advance, balance before shipment. L/C is also available.
