10kv XLPE Insulated Overhead Electric Transmission Aerial Bundle Cable

10kv XLPE Insulated Overhead Electric Transmission Aerial Bundle Cable

10kv XLPE Insulated Overhead Electric Transmission Aerial Bundle Cable
10kv XLPE Insulated Overhead Electric Transmission Aerial Bundle Cable
10kv XLPE Insulated Overhead Electric Transmission Aerial Bundle Cable
Product Details:
Place of Origin: Henan
Brand Name: Sanwu
Certification: ISO CCC
Model Number: xlpe insulated cables
Payment & Shipping Terms:
Minimum Order Quantity: 1000M
Price: USD 0.2-20 per meter
Packaging Details: wooden drums
Delivery Time: 1-15days
Payment Terms: L/C, T/T
Supply Ability: 200 tons per day
Contact Now
Detailed Product Description
Name: XLPE Shielded Cable Insulation: XLPE
Rated Voltage: 0.6-1kv Standard: IEC 60502-1
Sheath: PVC Package: Wooden Drum
Conductor Type: Stranded Application: Power Distribution, Construction, Underground, Etc.
Highlight:

10kv XLPE insulated overhead cable

,

aerial bundle transmission cable

,

XLPE insulated electric cable

10kV XLPE Insulated Overhead Electric Transmission Aerial Bundle Cable
This aerial bundle cable is designed for medium-voltage overhead transmission at 10kV, featuring aluminium or aluminium-alloy conductors insulated with cross-linked polyethylene (XLPE). The compact, self-supporting assembly provides stable dielectric performance under continuous load and transient overvoltage conditions. The helical stranding maintains consistent phase spacing, eliminating the need for separate spacers and reducing the visual and physical footprint of transmission lines.
Technical Standards
IEC 60502-1
Specifications
Specification mm² Conductor Structure Insulation Material Insulation Thickness (mm) Approx Overall Diameter (mm) Approx Weight (kg/km)
1*16+1*167/1.72XLPE Or1.212.5110.1
1*25+1*257/2.151.214.9163.9
1*35+1*357/2.54PVC or PE1.417.5229.0
1*50+1*507/2.921.420.1300.0
1*70+1*7019/2.151.423.6423.2
1*95+1*9519/2.541.627.6585.4
2*16+1*167/1.721.214.2175.8
2*25+1*257/2.151.216.7258.4
2*35+1*357/2.541.419.7361.2
2*50+1*507/2.921.422.5472.1
2*70+1*7019/2.151.426.1658.3
2*95+1*9519/2.541.630.5908.2
3*16+1*167/1.721.216.3241.5
3*25+1*257/2.151.219.1353.6
3*35+1*357/2.541.422.5493.5
3*50+1*507/2.921.425.7644.1
3*70+1*7019/2.151.429.7895.2
3*95+1*9519/2.541.634.61233.5
10kV XLPE Insulated Overhead Electric Transmission Aerial Bundle Cable product view
Manufacturing Process
Cable manufacturing process step 1 Cable manufacturing process step 2
Applications
  • Medium-Voltage Distribution Feeders - Supplying power from 10kV substations to load centers in towns, industrial zones, and large residential complexes
  • Urban Overhead Networks - Deployed along city streets and alleyways where limited clearance makes bare conductors impractical
  • Rural Transmission Extensions - Installed across agricultural land and forested areas to connect distant villages to the regional 10kV grid
  • Industrial Campus Power Backbones - Running overhead between factory buildings and process units for medium-voltage supply
  • Line Upgrades and Reconductoring - Replacing aged bare conductors on existing 10kV routes to enhance system reliability
Cable installation and application examples
Packaging & Delivery
Packaging Details
Wooden package optional. Sizes available: 0.5*0.5*0.5m, 0.6*0.6*0.6m, 0.7*0.7*0.7m, 1.1*1.1*0.8m, 2.2*2.2*1.8m, or customized dimensions according to your requirements.
Delivery Time
Generally 5-10 days if goods are in stock, or 15 days for custom orders.
Cable packaging and shipping illustration
Why Choose Us
  • Application-Specific Engineering - Designs consider mechanical and electrical demands of 10kV overhead transmission
  • Quality Assurance Programme - Each production run undergoes electrical tests and mechanical inspections
  • Installation and Maintenance Guidance - Detailed technical documentation provided for proper field installation
  • Customisable Configurations - Accommodate variations in conductor material, cross-section, and color coding
Frequently Asked Questions
Q: Are you trading company or manufacturer?
A: We are manufacturer.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock, or 15-20 days if the goods are not in stock, depending on quantity.
Q: Do you provide samples? Is it free or extra?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment?
A: Payment <=1000USD, 100% in advance. Payment >=1000USD, 30% T/T in advance, balance before shipment. L/C is also available.
